Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer

Independent Suspension Type : Trailing Arm Type

Shape : Flatbed

Axle Number : 3 Axles

Tire Number : 12 Linglong Tyres

Self-dumping : Not Self-dumping

ABS Anti-lock Braking System : ABS Anti-lock Braking System

Material : Steel

Condition : New

Tyre : 11.00r20,12.00r20, Linglong,Double Coin

Braking System : Dual Lines Pneumatic Brake

Langding Gear : Fuwa 28t Landing Gear

Axles : Fuwa, BPW 13t,16t,20t

Leaf Spring : 10/10/10

Electrical : 24V,

King Pin : 50# &90#

Transport Package : Bulk Cargo Ship or RO-RO

Specification : 100

Trademark : FOREVER

Origin : China

Supply Ability : 2000

Type : Semi-Trailer

Load Capacity : 30T

Certification : ISO9001, CCC

Wheel Base : 9000-10000mm

Tread : 1820mm

Grade : Heavy Duty

Customization : Available | Customized Request

Contact Now

Product Description

Company Info.

Customer Question & Answer
Ask something for more details

Basic Info.

Independent Suspension Type
Trailing Arm Type
Shape
Flatbed
Axle Number
3 Axles
Tire Number
12 Linglong Tyres
Self-dumping
Not Self-dumping
ABS Anti-lock Braking System
ABS Anti-lock Braking System
Material
Steel
Condition
New
Tyre
11.00r20,12.00r20, Linglong,Double Coin
Braking System
Dual Lines Pneumatic Brake
Langding Gear
Fuwa 28t Landing Gear
Axles
Fuwa, BPW 13t,16t,20t
Leaf Spring
10/10/10
Electrical
24V,
King Pin
50# &90#
Transport Package
Bulk Cargo Ship or RO-RO
Specification
100
Trademark
FOREVER
Origin
China
Production Capacity
2000

Product Description

Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer

MAIN PERFORMANCE
Product Specification
1Type Semitrailer
2Product NameLow Bed Semitrailer
3Dimension13000x3000x1600mm
4Tare Weight9230kg
5Payload41t
6


Running SystemAxlesFUWA , BPW, HUAJIN brand,13t/16t/20t Good quality axles
SuspensionTri-axle 10-pcs leaf spring suspension with equalizer beam
(we can choose the Air suspension depend on customer requirement)
TiresLinglong, Double Coin, Triangle brand 11.00R20/8.25R20/12.00R22.5, 12unit
7LadderManually operated or Hydraulic type
8Braking SystemDual lines pneumatic brake system, WABCO Emergency
Relay Valve; KORMEE ABS braking system
9FrameMain BeamQ345B steel,Height 500, upper 16mm,
lower 18mm. Mid web 10mm
Cross BeamMild Alloy Q235
10King PinSize: 50# (2'') or 90#(3.5''); Type: welded or assembled
11Landing GearFUWA, JOST Brand Single side operation or double side operation,
Static capacity 28Ton
12Electrical & Paint ElectricalRear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light
Lights & Reflectors24V, 7 lines
Paintingzinc-rich primer and modified urethane topcoat as customers' choices.
AccessoriesTOOL BOX (BOX ONLY)---PROVIDED WITH THE TRAILER
TWO SPARE WHEEL HOLDER(WINCH),BUT NO SPARE TYRES


I.The Application and the Technical Highlights:

---The low bed semitrailers are mainly suitable for the MID/Long distance transportation of mechanical equipment, large objects, highway construction equipment, large tanks, power plant equipment or machine, and all sorts of steel products.

---The low bed semitrailer can bed divide into flat bed low bed trailer, concave low bed trailer, tyres appear low bed trailer, tyres covered low bed trailer. The concave low bed trailer structured with tyre appeared style, the height of the cargo's carrying platform from ground is 900mm.-Low platform makes the stable transportation.

---The chassis is ladder type,longitudinal beam section is H-shaped. It has good rigidity and high strength.
--- High Quality Body and high-tensile steel for heavy loading capacity
--- BPW, FUWA or Certificated Chinese Axles
---ABS brake system
---WABCO Vehicle Control System
---JOST ,FUWA or Chinese brand parking leg and king pin
---Air and Mechanical Suspension
---Strengthen the Chassis Instructure
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer

II.The Advantage
***Frame:using the advanced assembly welded equipments to weld the space frame structure which formed by welded-type longitudinal beam (made of 16Mn steel plate) and the whole Run-through cross beam.Our consider the strength,stiffness and toughness of the frame and design the frame is strong enough to carry the heavy cargo.
***Suspension: Lightweight design.High-strength material with strong carrying capacity, remarkable wear resistance property and performance stability and long service life.Wheel Track adjustable easily and accurately, which protect the tires from abnormal wear.Passed strict bench testing and road testing.
***Axle:Specially processed one-piece spindle of high quality low alloy steel, which possesses strong loading capacity, long life, light weight and remarkable performance.High machining precision of the braking system makes the braking performance more stable.
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer


III.Advanced Process
~~~Design Drawing: Before production, we will sent the design drawing to our customer to confirm the detail of the vehicle. We hope we can supply the most suitable product to our customer.

~~~Cutting and Welding: The I beam cutting adopt the Computer Numerical Control Plasma Cutting Machine. The I beam welding adopt the Gantry Main Sill Welding Machine.

~~~The Beam Welding: Main beam and side beam all use I-shaped beam, it can ensure the trailer more durable.Reinforced rear plate can avoid the rear plate was broken away when heavy duty machines climbing the ramp of trailer.

~~~Surface Treatment: In order to remove the rust of the trailer body, we use the sand blasting to retreat the surface of the trailer.
The trailer can have the beautiful appearance,the painting will be coating evenly, firm adhension, gloss more durable

~~~Painting: One layer of the anti-rust painting, two layer of painting

~~~Test: We will test the quality of the trailer before delivery.
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer



IV.The Detail of the Low Bed Trailer
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer


V. Classification Of The Low Bed Trailer
Weifang Forever Low Bed Trailer, Lowbed Semi Trailers and Truck Trailers Machines Carrier 4 Axles 80 Tons Low Bed Lowbed Semi Trailer

VI. Guarrantee For The Parts Of The Low Bed Traielr:
ITEM NAMEWARRANTYITEM NAMEWARRANTY
MAIN FRAMEFRAME1 YEARRUNNING GEARAXLE6 MONTHS
SUSPENSION6 MONTHSAXLE BEARING3 MONTHS
KING PIN1 YEARWHEEL HUB3 MONTHS
BALANCE ARM3 MONTHS
ITEM NAMEWARRANTYITEM NAMEWARRANTY
BRAKING DEVICEBRAKE DRUM3 MONTHSSUPPORT DEVICELANDING GEAR6 MONTHS
BRKE CHAMBER3 MONTHSSPARE WHEEL CARRIER6 MONTHS
AIR RESERVOIR6 MONTHS
ITEM NAMEWARRANTY
OTHERSLEAF SPRING3 MONTHS
BRAKE CHAMBER DIAPHRAGM3 MONTHS
EMERGENCY RELAY VALVE3 MONTHS
BRAKE SHOE3 MONTHS
RELAY VALVE3 MONTHS

VII. DEALING PROCESS

1. You send us an inquiries on your desired trailer through our contact information.
2. We shall reply you in 12 hours after we received our inquiry.
3. We will negotiate the detail of the trailer on your requirement.
4. Confirmed on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. The Manufacturig process with updated news.
9. The Production completement.
10.Balance payment .
11.Arrange Shipment and Custom Clearance
12. A/S service for 1 year.
